DIN 2510-6 bolted connections with reduced shank cap nuts



Thread  d1
M12
M16
M20
M24
M27
M30
M33
M36
M39
M42
M45
b
18
20.5
24
27.5
30.5
35
38
40.5
43
46
48.5
d2
21
26
31
35
40
45
49
53.5
58.5
63.5
68.5
d3
14.5
18.5
22.5
26.5
30.5
33.5
36.5
39.5
42.5
45.5
49.5
d4
9
13
15
17.5
20
23
26
28
31.5
33.5
36
d5
4
6
6
10
10
10
10
10
10
10
10
e min.
18.90
21.10
26.75
30.14
35.72
39.98
45.63
45.63
51.28
55.80
55.80
k
7
10
13
14
16
17
22
22
23
23
26
l1
33
40
49
56
62
68
77
82
86
92
98
l2
29.5
34.5
40
45.5
50.5
55
60
64.5
67
72
74.5
l3
23
27.5
32
37.5
40.5
45
48
52.5
55
60
62.5
g
13
17
21
25
28
31
34
37
40
43
46
s
17
19
24
27
32
36
41
41
46
50
50
t
2
2
2.5
3
3
3.5
3.5
4
4
4.5
4.5
Thread  d1
M48
M52
M56
M64
M72*6
M80*6
M90*6
M100*6
M110*6
(M120*6)
b
53.5
57
60.5
69.5
77
84
93
102
111
120
d2
73.5
78.5
83.5
93.5
105
115
130
146
160
176
d3
53.5
57.5
63
71
79
87
97
107
119
129
d4
39
42
47.5
54
58
65
77
89
100
108
d5
10
10
10
/
/
/
/
/
/
/
e min.
61.31
66.96
72.61
83.91
89.56
100.72
117.67
134.62
151.42
162.72
k
26
27
27
32
32
36
41
45
50
54
l1
103
109
115
130
140
152
168
183
199
214
l2
815
85
90.5
99.5
107
114
123
132
141
152
l3
67.5
71
76.5
85.5
93
100
109
118
127
136
g
49
53
57
65
73
81
91
101
111
121
s
55
60
65
75
80
90
105
120
135
145
t
5
5
5.5
6
6
6
6
6
6
6

Tags: DIN 2510-6 Cap Nuts

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
