DIN 960 - hexagon head bolts with fine pitch thread



Thread size (d)
M8*1
M10*1
M12*1.5
(M14*1.5)
(M16*1.5)
(M18*2)
M20*1.5
(M22*2)
M24*2
/
M10*1.25
M12*1.25
/
/
(M18*1.5)
M20*2
(M22*1.5)
M24*1.5
b
l≤125mm
22
26
30
34
38
42
46
50
54
125mm<l≤200mm
28
32
36
40
44
48
52
56
60
200mm <l
41
45
49
53
57
61
65
69
73
c

min.
0.15
0.15
0.15
0.15
0.2
0.2
0.2
0.2
0.2

max.
0.6
0.6
0.6
0.6
0.8
0.8
0.8
0.8
0.8
da

max.
9.2
11.2
13.7
15.7
17.7
20.2
22.4
24.4
26.4
ds min.

max.
8
10
12
14
16
18
20
22
24
Product grade A
7.78
9.78
11.73
13.73
15.73
17.73
19.67
21.67
23.67
Product grade B
7.64
9.64
11.57
13.57
15.57
17.57
19.48
21.48
23.48
dw  min.
Product grade A
11.6
15.6
17.4
20.5
22.5
25.3
28.2
30
33.6
Product grade B
11.4
15.4
17.2
20.1
22
24.8
27.7
29.5
33.2
e min.
Product grade A
14.38
18.9
21.1
24.49
26.75
30.14
33.53
35.72
39.98
Product grade B
14.2
18.72
20.88
23.91
26.17
29.56
32.95
35.03
39.55
k

Nominal size
5.3
6.4
7.5
8.8
10
11.5
12.5
14
15
Product grade  A min.
5.15
6.22
7.32
8.62
9.82
11.28
12.28
13.78
14.78
Product grade  A max.
5.45
6.58
7.68
8.96
10.18
11.72
12.72
14.22
15.22
Product grade  B min.
5.06
6.11
7.21
8.51
9.71
11.15
12.15
13.65
14.65
Product grade  B max.
5.54
6.69
7.79
9.09
10.29
11.85
12.85
14.35
15.35
k'
min.
3.54
4.28
5.05
5.96
6.8
7.8
8.5
9.6
10.3
r
min.
0.4
0.4
0.6
0.6
0.6
0.6
0.8
0.8
0.8
s  min.
max.= nominal size
13
17
19
22
24
27
30
32
36
Product grade  A min.
12.73
16.73
18.67
21.67
23.67
26.67
29.67
31.61
35.38
Product grade  A max.
12.57
16.57
18.48
21.16
23.16
26.16
29.16
31
35
Thread size (d)
(M27*2)
M30*2
(M33*2)
M36*3
(M39*3)
M42*3
(M45*3)
M48*3
(M52*3)
b
l≤125mm
60
66
72
78
84
90
98
102
/
125mm<l≤200mm
66
72
78
84
90
96
102
108
116
200mm <l
79
85
91
97
103
109
115
121
129
c
min.
0.2
0.2
0.2
0.2
0.3
0.3
0.3
0.3
0.3
　

max.
0.8
0.8
0.8
0.8
1
1
1
1
1
da
max.
30.4
33.4
36.4
39.4
42.4
45.6
48.6
52.6
58.6
ds
max.
27
30
33
36
39
42
45
48
52
min.
26.48
29.48
32.38
35.38
38.38
41.38
44.38
47.38
51.26
dw
min.
38
42.7
46.6
51.1
55.9
59.9
64.7
69.4
74.2
e
min.
45.2
50.85
55.37
60.79
66.44
71.3
76.95
82.6
88.25
k

Nominal size
17
18.7
21
22.5
25
26
28
30
33
min.
16.65
18.28
20.58
22.08
24.58
25.58
27.58
29.58
32.5
max.
17.35
19.12
21.42
22.92
25.42
26.42
28.42
30.42
33.5
k'
min.
11.7
12.8
14.4
15.5
17.2
17.9
19.3
20.9
22.8
r
min.
1
1
1
1
1
1.2
1.2
1.6
1.6
s  min.
max.= nominal size
41
46
50
55
60
65
70
75
80
min.
40
45
49
53.8
58.8
63.1
68.1
73.1
78.1
Thread size (d)
M56*4
(M60*4)
M64*4
(M68*4)
M72*4
(M76*4)
M80*4
M90*4
M100*4
b
125mm<l≤200mm
124
132
140
148
156
164
172
192
/
200mm <l
137
145
153
161
169
177
185
205
225
c
min.
/
/
/
/
/
/
/
/
/
　

max.
1
1
1
1
1
1
2
2
2
da
max.
63
67
71
75
79
83
87
97
108
ds
max.
56
60
64
68
72
76
80
90
100
min.
55.26
59.26
63.26
67.26
71.26
75.26
79.26
89.13
99.13
dw
min.
78.7
83.4
88.2
92.9
97.7
102.4
107.2
121.1
135.4
e
min.
93.58
99.21
104.86
110.51
116.16
121.81
127.46
144.08
161.03
k

Nominal size
35
38
40
43
45
48
50
57
63
min.
34.5
37.5
39.5
42.5
44.5
47.5
49.5
56.4
62.4
max.
35.5
38.5
40.5
443.5
45.5
48.5
50.5
57.6
63.3
k'
min.
24.2
26.2
27.6
29.8
31.2
33.2
34.6
39.5
43.7
r
min.
2
2
2
2
2
2
2
2.5
2.5
s  min.
max.= nominal size
85
90
95
100
105
110
115
130
145
min.
82.8
87.8
92.8
97.8
102.8
107.8
112.8
127.5
142.5
