DIN 1476 - Round Head Grooved Pins



d1
Nominal
1.4
1.6
2
2.5
3
4
5
6
8
10
12
16
20
Tolerance
0
-0.05
0
-0.075
0
-0.1
0
-0.15
0
-0.2
d3


2.4
2.8
3.5
4.4
5.2
7
8.8
10.5
14
16
19
25
32
Tolerance
±0.2
±0.25
±0.3
±0.4
0 -1.1
0 -1.3
k


0.8
1
1.2
1.5
1.8
2.4
3
3.6
4.8
6.5
7.5
10
13
Tolerance
±0.1
±0.15
±0.2
+0.9  0
r≈
1.4
1.6
1.9
2.4
2.8
3.8
4.6
5.7
7.5
8
9.5
13
16.5
f≈
0.5
0.7
1
1.5
2
2.5
3
l js15
d2
3
1.5
1.7
2.15
2.7


















4
3.2
















5
















6
4.25














8




5.25
6.3










10




8.3








12








10.35






16








12.35




20










16.4


25












20.5
30














35














40
















Tolerance for d2
+0.05 0
±0.05
±0.1

Tags: DIN 1476 Round Head Grooved Pins

General Material:Stainless Steel,Nickel Alloy,Silicon Bronze,Aluminium Bronze,Brass,Naval Brass,Coppe,Copper-Nickel,Aluminum Alloy,Titanium,Alloy Steel,Such as C1008,C1018,C1022,C1035,C1045,40cr,SCM435,35crmoA,42crmoA,AISI4140SS304/A2-70,SS316/A4-80,SS310s,SS309,SS321,SS410,SS317,SS904L,17-4 PH/630,Duplex 2205,Duplex 31803,Nitronic 40,Nitronic 50,Nitronic 60,Nickel Alloy,Hastelloy C276,Inconel 600,Inconel 601,Inconel 625,Inconel 718,Inconel X750,Inconel 800H,Inconel 825,Monel 400,Monel 405,Monel K-500,MP35N,Nickel 200,Nickel 201,Waspaloy)C65500,C64200,C61400,C63000,C63200,C46200,H59,H62,H67,C46400,C11000,90/10 C70600,70/30 C71500,6061-T6,2024-T4,Ti-6Al-4V Grade 5,ASTM B348 Grade 2,ASTM B348 Grade 7,651/S63198
General Surface Finish:Blackoxide,Zinc,Dacromet 500/Dacromet 320,Non-electrolytically Deposited Zinc Flake,Hot-dip Galvanization,Phosphating,Passviation
