DIN 985 - prevailing torque type hexagon thin nuts with nonmetallic insert



Thread d
M3
M4
M5
M6
M7
M8
M10
M12
M14
M16
M18
/
/
/
/
/
M8*1
M10*1
M12*1.5
M14*1.5
M16*1.5
M18*2
/
/
/
/
/
/
M10*1.25
M12*1.25
/
/
M18*1.5
P
0.5
0.7
0.8
1
1
1.25
1.5
1.75
2
2
2.5
da
min.
3
4
5
6
7
8
10
12
14
16
18
max.
3.45
4.6
5.75
6.75
7.75
8.75
10.8
13
15.1
17.3
19.5
dw

min.
4.6
5.9
6.9
8.9
9.6
11.6
15.6
17.4
20.5
22.5
24.9
e
min.
6.01
7.66
8.79
11.05
12.12
14.38
18.9
21.1
24.49
26.75
29.56
h
max.=nominal size
4
5
5
6
7.5
8
10
12
14
16
18.5

min.
3.7
4.7
4.7
5.7
7.14
7.64
9.64
11.57
13.3
15.3
17.66
m

min.
2.4
2.9
3.2
4
4.7
5.5
6.5
8
9.5
10.5
13
m'

min.
1.65
2.2
2.75
3.3
3.85
4.4
6.43
6.6
7.7
8.8
9.9
S
max.=nominal size
5.5
7
8
10
11
13
17
19
22
24
27

min.
5.32
6.78
7.78
9.78
10.73
12.73
16.73
18.67
21.67
23.67
26.16
Thread d
M20*2
M22
M24
M27
M30
M33
M36
M39
M42
M45
M48
M20*2
M22*2
M24*2
M27*2
M30*2
M33*2
M36*3
M39*3
M42*3
M45*3
M48*3
M20*1.5
M22*1.5
/
/
/
/
/
/
/
/
/
P
2.5
2.5
3
3
3.5
3.5
4
4
4.5
4.5
5
da

min.
20
22
24
27
30
33
36
39
42
45
48
max.
21.6
23.7
25.9
29.1
32.4
35.6
38.9
42.1
45.4
48.6
51.8
dw

min.
27.7
29.5
33.2
38
42.7
46.6
51.1
55.9
60.6
64.7
69.4
e
min.
32.95
35.03
39.55
45.2
50.85
55.37
60.79
66.44
72.09
76.95
82.6
h
max.=nominal size
20
22
24
27
30
33
36
39
42
45
48

min.
18.7
20.7
22.7
25.7
28.7
31.4
34.4
37.4
40.4
43.4
46.4
m

min.
14
15
15
17
19
22
25
27
29
32
36
m'

min.
11
12.2
13.2
14.8
16.5
18.2
19.8
21.5
23.1
24.8
26.5
S
max.=nominal size
30
32
36
41
46
50
55
60
65
70
75

min.
29.16
31
35
40
45
49
53.8
58.8
63.8
68.1
73.1
